IAI America XSEL Ethernet - Manual (Page 26)

- 20 -
[Modbus/TCP output areas (assignment of X-SEL DI area 300 onward), FMIO = 0]
Address
BIT7
(MSB)
6 5 4 3 2 1
0
(LSB)
X-SEL DI 7 6 5 4 3 2 1 0
Modbus/TCP bit address 16384 16385 16386 16387 16388 16389 16390 16391
Modbus/TCP word address 1024 Lower byte
Modbus output coil 1 2 3 4 5 6 7 8
Modbus hold register 40001 Lower byte
X-SEL DI 15 14 13 14 15 10 9 8
Modbus/TCP bit address 16392 16393 16394 16395 16396 16397 16398 16399
Modbus/TCP word address 1024 Upper byte
Modbus output coil 9 10 11 12 13 14 15 16
Modbus hold register 40001 Upper byte
:
:
X-SEL DI 247 246 245 244 243 242 241 240
Modbus/TCP bit address 16624 16625 16626 16627 16628 16629 16630 16631
Modbus/TCP word address 1039 Lower byte
Modbus output coil 241 242 243 244 245 246 247 248
Modbus hold register 40016 Lower byte
X-SEL DI 255 254 253 252 251 250 249 248
Modbus/TCP bit address 16632 16633 16634 16635 16636 16637 16638 16639
Modbus/TCP word address 1039 Upper byte
Modbus output coil 249 250 251 252 253 254 255 256
Modbus hold register 40016 Upper byte
Cannot be used
