Names of the Parts
In this manual, the right and left sides of the actuator are expressed in the way it is placed
horizontally as shown in the figure below, and is looked at from the motor side.
Ɣ Without brake type
Rod
Width across flats
Pipe
Cable
Encoder cover
Front
Rear
Ɣ With brake type
Rear
Front
Rod
Brake cable
Motor, Encoder cable
Width across flats
Pipe
Encoder cover
