!35! Green! Bit 4! Error Input #29 To Kp-300 Expansion
!36! Blue! Bit 3! Error Input #28 To Kp-300 Expansion
!37! Violet! Bit 2! Error Input #27 To Kp-300 Expansion
!38! Gray! Bit 1! Error Input #26 To Kp-300 Expansion
!39! White! Bit 0! Error Input #25 To Kp-300 Expansion
!40! Black! ! + 24 Vdc Supply
