1) Green ʻPauseʼ Output from Kp-300
This output is activated when there is a Show Pause event on the Kp-300. This
event causes the Pause Buss to go active, which causes the Show Pause Buss
LED to be lit. The Green ʻPauseʼ Output from Kp-300 is used to tell the Smart
Brick Brain to initiate a Show Pause through its Green ʻPauseʼ Output . The Smart
Brick Brain input must be configured to pause the currently running show on a clo-
sure on this input
18 . When a show is 'continued', the signal is dropped on the
Green ʻPauseʼ Output to the Smart Brick Brain. This input must be configured to
continue the currently running show on a opening on this input.
Once a show has been paused, the only two ways to 'continue' a show are to:
a) Send an active signal from the Smart Brick System to the Kp-300ʼs
Show Pause Reset Input .
b) Once the condition that caused the Show Pause has been re-
moved, the operator can press the Show Continue button .
2) Blue ʻE-Stopʼ Output from Kp-300
This output is activated when there is an E-Stop event on the Kp-300. It is used
to tell the Smart Brick Brain to start playing the E-Stop show. The Smart Brick
Brain must be configured to select and start the E-Stop show when it receives a
closure on this input.
Gilderfluke & Co.• 205 South Flower Street • Burbank, California 91502 • 818/840-9484 • 800/776-5972 • fax 818/840-9485
Kp-300 Manual / September 4, 2012 4:29 PM / page 63 of 75
18 In some applications, you may want to call up a different show using this input, instead of pausing the current show.
