E) HPU Stop Button

This Button is used to reset the latch on the Kp-300 that turns on the

HPU

Run Output

. This is an optional feature. If you donʼt want the HPU to be

started and stopped remotely, just donʼt use this button.

The

HPU Stop Button

parallels the

Remote HPU Stop Input

from the

Smart Brick System.

F) Show Pause Button

This button is used to set the latch on the Kp-300 that sends a pause

command to the Smart Brick Brain through the

Green ʻPauseʼ Output

. This

latch can also be set by any error condition that has been configured to start
a Show Pause event. If the

Show Pause Reset Output

from the Smart Brick

System is active, then the Show Pause latch can not be set by either this
button or an error condition.

When a show is paused, the Kp-300 sends a signal to the Smart Brick

Brain through its

Green ʻPauseʼ Output

. The Smart Brick Brain input must be

configured to pause the currently running show on a closure on this input

When a show is 'continued', the signal is dropped on the

Green ʻPauseʼ

Output

to the Smart Brick Brain. This input must be configured to continue

the currently running show on an opening on this input.

Once a show has been paused, the only two ways to 'continue' a show

are to:

a) Send an active signal from the Smart Brick System to the Kp-

300ʼs

Show Pause Reset Input

b) Once the condition that caused the Show Pause has been re-

moved, the operator can press the

Show Continue button

G) Show Continue Button

This button is used to reset the latch on the Kp-300 that sends a pause com-

mand to the Smart Brick Brain through the

Green ʻPauseʼ Output

. This latch can

also be set by any error condition that has been configured to start a Show Pause
event.

When a show is paused, the Kp-300 sends a signal to the Smart Brick Brain

through its

Green ʻPauseʼ Output

. The Smart Brick Brain input must be configured

Gilderfluke & Co.• 205 South Flower Street • Burbank, California 91502 • 818/840-9484 • 800/776-5972 • fax 818/840-9485

Kp-300 Manual / September 4, 2012 4:29 PM / page 25 of 75

In some applications, you may want to call up a different show using this input, instead of pausing the current show.
