Kp-300 Outputs to Smart Brick Brain
(20 P OSITION R IBBON C ABLE C ONNECTOR )
This connector is used to send messages and show requests from the Kp-300 to the
Smart Brick Brain. More information on these connection can be found in the Smart
Brick System manual sections on the Rack Mounted Smart Brick Brain:
! Wire #!Color! Bit #! Description
! 1! Brown! n/a! Ground
! 2! Red! Bit 7! Show Select Output #8
! 3! Orange!Bit 6! Show Select Output #7
! 4! Yellow! Bit 5! Show Select Output #6
! 5! Green! Bit 4! Show Select Output #5
! 6! Blue! Bit 3! Show Select Output #4
! 7! Violet! Bit 2! Show Select Output #3
! 8! Gray! Bit 1! Show Select Output #2
! 9! White! Bit 0! Show Select Output #1
! 10! Black! n/a! + 24 vdc Supply to Smart Brick Brain 1/4 J6 Input
! 11! Brown! n/a! (not used on Kp-300)
! 12! Red! n/a! (not used on Kp-300)
! 13! Orange! n/a! (not used on Kp-300)
! 14! Yellow! n/a! (not used on Kp-300)
! 15! Green! n/a! (not used on Kp-300)
! 16! Blue! n/a! (not used on Kp-300)
! 17! Violet!Pause! - Green ʻPauseʼ Output to Smart Brick Brain
! 18! Gray! Pause! + Green ʻPauseʼ Output to Smart Brick Brain
! 19! White!E-Stop ! - Blue ʻE-Stopʼ Output to Smart Brick Brain
! 20! Black!E-Stop ! + Blue ʻE-Stopʼ Output to Smart Brick Brain
1) Show Select Outputs from Kp-300
These outputs are used to tell the Smart Brick Brain which show it should play.
They can only be activated if the corresponding Show Start Enable Inputs have
been activated by the program stored in the Smart Brick System.
If you need show start switches that are external to the Kp-300, just attach up
to eight momentary switches between the eight Show Start Enable Inputs and the
Show Select Outputs from the Kp-300. Any closure of these switches will be
treated exactly as if the operator had pressed the
Show Start Buttons on the front
of the Kp-300. You can even add Show Start Button LEDs to these external Show
Start Buttons by attaching LEDs (with suitable resistors) in parallel with the Show
Start Button LEDs . You can also attach a Kp-100 or Kp-200 to the Show Select
Outputs if you need to access more than eight shows from the Kp-300. Please
contact the factory for details on how this is done.
