The 24 vdc supply and ground lines can be used to power sensors or other de-
vices. They are PTC fused for 1.1 amp of current.
4) Thirty-two Optoisolated Inputs To The Kp-300 Expansion
(40 P OSITION J6 S HROUDED M ALE H EADER )
This connector is used for thirty-two more optically isolated Inputs to the Kp-
300 Expansion. You must provide power to this input on the ʻ+24 vdc Supplyʼ pins,
and ground the inputs to the same power supply to make them active.
!
Wire #!Color! Bit #! Description
! 1! Brown! ! Ground
! 2! Red! Bit 7! Error Input #8 To Kp-300 Expansion
! 3! Orange!Bit 6! Error Input #7 To Kp-300 Expansion
! 4! Yellow! Bit 5! Error Input #6 To Kp-300 Expansion
! 5! Green! Bit 4! Error Input #5 To Kp-300 Expansion
! 6! Blue! Bit 3! Error Input #4 To Kp-300 Expansion
! 7! Violet! Bit 2! Error Input #3 To Kp-300 Expansion
! 8! Gray! Bit 1! Error Input #2 To Kp-300 Expansion
! 9! White! Bit 0! Error Input #1 To Kp-300 Expansion
!10! Black! ! + 24 Vdc Supply
!11! Brown! ! Ground
!12! Red! Bit 7! Error Input #16 To Kp-300 Expansion
!13! Orange!Bit 6! Error Input #15 To Kp-300 Expansion
!14! Yellow! Bit 5! Error Input #14 To Kp-300 Expansion
!15! Green! Bit 4! Error Input #13 To Kp-300 Expansion
!16! Blue! Bit 3! Error Input #12 To Kp-300 Expansion
!17! Violet! Bit 2! Error Input #11 To Kp-300 Expansion
!18! Gray! Bit 1! Error Input #10 To Kp-300 Expansion
!19! White! Bit 0! Error Input #9 To Kp-300 Expansion
!20! Black! ! + 24 Vdc Supply
!21! Brown! ! Ground
!22! Red! Bit 7! Error Input #24 To Kp-300 Expansion
!23! Orange!Bit 6! Error Input #23 To Kp-300 Expansion
!24! Yellow! Bit 5! Error Input #22 To Kp-300 Expansion
!25! Green! Bit 4! Error Input #21 To Kp-300 Expansion
!26! Blue! Bit 3! Error Input #20 To Kp-300 Expansion
!27! Violet! Bit 2! Error Input #19 To Kp-300 Expansion
!28! Gray! Bit 1! Error Input #18 To Kp-300 Expansion
!29! White! Bit 0! Error Input #17 To Kp-300 Expansion
!30! Black! ! + 24 Vdc Supply
!31! Brown! ! Ground
!32! Red! Bit 7! Error Input #32 To Kp-300 Expansion
!33! Orange!Bit 6! Error Input #31 To Kp-300 Expansion
!34! Yellow! Bit 5! Error Input #30 To Kp-300 Expansion
