the safety inputs can be logged by either pressing the
activating the
attached to it. If you want to automatically log belts from the motion
profile, just set the
for Internal Power and attach the
two wires for this input together so it is always active. Whenever the
is programmed active, the inputs that are set to be
logged will automatically be logged.
Input logging actually takes place at the instant that the
are released.
E) Show Start Button LEDs
(One green LED for each Show Start Button)
!
(Eight LEDs total)
These LEDs are controlled directly by the motion control profile stored in
the Smart Brick System. This allows the LEDs to be programmed on, off or
flashing as desired at any point in time. They are programmed to indicate
which shows are available to the operator, or to indicate which show is al-
ready running. We typically program them in a chase pattern, lighting only
the valid show selections. Once a show has started, we typically program all
but the selected
off, and flash the selected show
LED a few times before turning it on through the rest of the show. If any
other show selection is valid while another show is running, we then flash it
discretely throughout the show that is running.
is programed to indicate that a
is valid, it is also necessary to actually enable the correspond-
ing
Show Start Button Enable Input
output from the Smart Brick System to
make the
active. If this is not done, then the
F) Show Cycle Counter LED
(One green LED)
This LED lights to show that the show cycle counter has been com-
manded to advance by the motion control profile stored in the Smart Brick
System. The count on the LCD counter will advance by one if the Kp-300 is
not currently in any type of E-Stop condition and the HPU is running, as indi-
cated by 24 vdc being received on the
.
