a) The motion base is programmed with all axis at the parked posi-

tions. This can be seen in the upper, analog data pane. All the ana-
log channels are down along the bottom ʻ0%ʼ line in the E-Stop and
Load/Unload Shows.

b) Disable the

Blocking Valve Output

to the Kp-300. This will park a

hydraulic Motion base (the hardware on the Kp-300 will have actu-
ally turned off the output before this). The ʻBlocking Valveʼ output is
ʻoffʼ through all four seconds of this show.

c) Turn on the ʻ

E-Stop Show Running

ʼ Output to the Kp-300. If you

donʼt do this, you wonʼt be able to restart the HPU to get yourself
out of the E-Stop event. The ʻE-Stop Showʼ output is ʻonʼ through
the entire show.

d) Turn on any of the

Bypass Outputs

that are needed to recover from

the E-Stop event. In this application, the ʻBypass 1ʼ is used during
the E-Stop and Load/Unload shows to keep the doors being
opened and people walking in and out from triggering additional E-
Stops.

e) Flash the

Show Start Button LED(s)

for whatever show(s) you want

the operator to be able to call up next. This is so the operator knows
which show options are available. We typically program them in a
chase pattern during the E-Stop and Load/Unload shows, lighting
only the valid show selections. The eight ʻShow Pilotʼ outputs are
shown doing a simple circular chase pattern.

f) Whenever a

Show Start Button LED

is programed to indicate that a

Show Start Buttons

is valid, it is also necessary to actually enable

the corresponding

Show Start Button Enable Input

from the Smart

Brick System to make the

Show Start Buttons

active. If this is not

done, then the
