DipSwitch settings on the Kp-300 (v3.0+)
(E
IGHT
P
OSITION
D
IP
S
WITCH
)
The DipSwitch is used to select several options on the v3.0+ Kp-300s:
A) DipSwitch #1:
Internal/External
OFF# =
controlled by an external switch
ON# =
controlled internally
If your HPU has a switch that closes when the HPU is not running, you
should wire this switch to the
pins #1 and #14 on the J2
connector. If your HPU doesnʼt have a ʻstoppedʼ switch output, or you donʼt
even have a HPU in your application, turning this switch on will light the
when the Kp-300 thinks the HPU shouldnʼt be running.
Unlike the
, the
is not used for any
other purpose than lighting this LED.
B) DipSwitch #2:
OFF# =
controlled by an external switch
ON# =
controlled internally
If your HPU has a switch that closes when the HPU is not running, you
should wire this switch to the
pins #2 and #15 on the J2
connector. If your HPU doesnʼt have a ʻstoppedʼ switch output, or you donʼt
even have a HPU in your application, turning this switch on will light the
when the Kp-300 thinks the HPU shouldnʼt be running.
C) DipSwitch #3: E-Stop Disables Show Starts
OFF# = Does nothing
ON# = E-Stop Buss disables new show starts
When on, this DipSwitch will keep any shows from being started When
the
is lit) using the
, even if the
ʻShow Startʼ Enables
are active.
D) DipSwitch #4: HPU-Stop Disables Show Starts
OFF# = Does nothing
