DMX-512 Address Selection on the Kp-300 (v3.0+)

EXADECIMAL

WITCHES

)

To support the DMX-512 input, the v3.0+ Kp-300 adds a two position rotary

DipSwitch which is used to set the DMX-512 address

The DMX-512 addressing is zero-based, HEXadecimal numbering.

Valid addresses between 00h and FFh. We typically set the Kp-300 to an address of

00h thru 02h, and then address the motion base legs and outputs for starting the videos,
lights and ʻ4dʼ effects starting at 03h.

The Kp-300 requires DMX-512 that includes GilderChecksums. If receiving DMX-512

without valid checksums, the

on the back of the Kp-300 will not

flash and only the

will follow the incoming the DMX-512. The

signals like the

s, blocking valve enable, and automatic

will not work when the GilderChecksums are invalid.
