9. The following instructions should be used to mount the fifth wheel mounting kit. Care and attention to detail will
ensure a quick quality installation. Check parts against parts list to become familiar with parts in kit. (
Figure 1
)
10. If extra clearance is needed to install the frame brackets, raise the rear of the truck high enough to allow the rear
tires to hang down freely. This will provide the maximum room to install the fifth wheel brackets.
11. Remove plastic bed liner if applicable. Plastic drop-in bed liners will be cut later. (See
Figure 15
) Spray-in bed
liners and bed mats less than 1/4” thick will work with normal installation instructions. Note: Consult installer for
recommended curing time on spray-in liner before cutting holes through bed.
12. Use only
CEQUENT PERFORMANCE PRODUCTS, Inc.
supplied bolts, nuts, and washers to install this kit. All
bolts and nuts are Grade 8 unless specified otherwise.
13. These instructions are intended for 2011 Ford Super Duty with 6 to 8 foot bed. Each frame bracket must be bolted
to the vehicle frame with two bolts.
GENERAL INSTRUCTIONS FOR FIFTH WHEEL INSTALLATION
TOOLS
1/8" Drill Bit
15/16" Socket & Open End Wrench
Torx T50
IP Bit (Supplied with Kit)
200 lb-ft Torque Wrench
Rubber Mallet
2-3/4” Hole Saw
21mm Socket or Open End Wrench
19mm Socket or Open End Wrench
1/2” Drive Swivel Head Ratchet
3/8” Allen Wrench Socket
CAUTION!
Read pages 2-4 of these instructions before starting installation. Failure to do so could result in significant vehicle damage!
WARNING:
If the truck is raised, be sure that the truck is properly blocked and restrained to prevent the truck from falling.
Failure to do so may result in the truck suddenly falling, causing death or serious injury.
CAUTION:
Check for obstructions before drilling. Failure to do so could result in damaged fuel or brake lines, structural
members, etc.
CEQUENT PERFORMANCE PRODUCTS, Inc.
does its best to communicate tow vehicle
manufacturer changes; however, it is ultimately the responsibility of the installer to prevent damage due to
installation.
CAUTION:
These instructions are guidelines only. Actual installation is the responsibility of the installer and the owner.
Always measure truck and trailer before installing hitch to be sure that there is clearance at the cab and at the
bumper to allow for turns.
14. Drill 1/8”pilot holes in truck bed at outer dimpled locations (approximate dimensions of
Figure 15
). The middle
dimple is for the goose ball only. (See gooseneck instructions if applicable.) These dimpled locations are placed by
the factory. If dimples are not present, refer to (
Figure 15)
located on page 9. Use a 2 ¾” hole saw to cut hole at
pilot holes. Note: Consult installer for recommended curing time on spray in liner before cutting holes through bed.
Optional: Spray under coating around 2 ¾” holes to prevent rusting.
15. Locate the area where the base rails will be inserted above the rear wheel on the passengers side. There are two
hat channels supporting the truck bed over the rear wheel. The base rails will be inserted at the location behind
the forward hat channel
(FIGURE 8)
located on page 6. To create clearance for inserting the rails remove
passengers side bed bolts, loosen drivers side bed bolts with T50 torx bit (#14)
(Figure 1)
, and block up
passengers side bed.
WARNING:
Be careful of fuel fill line and wiring while lifting.
