INSTALLATION INSTRUCTIONS
Product No.
37016
You can take it with you.
SMALL PARTS
PACKAGE 37431
ELKHART, IN., OAKVILLE, ONT.
CHEVY & GMC PICKUP
WARNING: DO NOT LUBRICATE THREADS, BOLT FAILURE MAY
OCCUR DUE TO OVER TIGHTENING.
WARNING: DO NOT DRILL OR WELD TO THIS HITCH. IMPORTANT NOTES
USE ONLY REESE SUPPLIED OR APPROVED BOLTS, LOCKNUTS,
AND WASHERS TO INSTALL THIS HITCH
TOOLS REQUIRED
21mm SOCKET
3/4” SOCKET
TORQUE WRENCH
1/2" KNURLED BOLT
1/2" BLACK LOCK WASHER
1/2" BLACK NUT
EXISTING 14mm BOLT
1/2" CARRIAGE BOLT
BOLT PLATE
1/2" SERRATED WASHER
1/2" LOCK WASHER
1/2" NUT
(OVER)
1. Remove the 14mm bolt from the bottom of the bumper bracket on both sides of the vehicle. Align the brackets with these holes
and install the two existing 14mm bolts.
2. Insert the 1/2” carriage bolts through the bolt plates and down through the remaining holes in the frame and install 1/2”
serrated washer, 1/2” lock washer, and 1/2” nut. Leave all nuts loose.
For Installation Assistance or Technical Help, Call 1-800-758-0869
37016IN-1JAN99B PCN4352 © 1998 REESE PRODUCTS, INC. Litho in USA
