Installation Instructions

3” to 2” ADAPTER

Part Numbers:

38735N

Adapter Shown In Position

Equipment Required:

Wrenches: N/A

Drill Bits: None

1.

Insert 3” – 2” Adapter into the 3” receiver opening.

2.

Install the ¾” pin supplied with your 20K or 25K hitch or 25K ball mount and clip.

Rev. A

7-27-07

38735N

Sheet 1 of 1

z

2007 Cequent Towing Products

Note: check hitch frequently, making sure all fasteners and ball are properly tightened. A hitch or ball which has been damaged should be removed and replaced.
Observe safety precautions when working beneath a vehicle and wear eye protection. Do not cut access or attachment holes with a torch.
This product complies with safety specifications and requirements for connecting devices and towing systems of the state of New York, V.E.S.C. Regulation V-5 and
SAE J684.

12,000 LB (11340 Kg) Max Gross Trailer Weight

1,200 LB (1814.4 Kg.) Max Tongue Weight

Do Not Exceed Lower of Towing Vehicle

Manufacturer’s Rating or

Ball Mount

(Not supplied)

Fastener Kit: N/A

Form F206 Rev A 5605

Chassis

(Not Supplied)

3” – 2” Adapter Shown Assembled

Hitch (Not Supplied)

3” – 2” Adapter

3” – 2” Adapter

3” Receiver

Opening

¾” Hitch Pin
(See Note 2)

20K or 25K

Hitch

2” Ball Mount

Clip

INSTALLATION INSTRUCTIONS
