Page 95
* Customer must verify spindle part number located on outer housing, see page 13.
Part No.
Description
Qty
ATOMIZER RECOMMENDED SPARE PARTS
A12895-XX *
Air Turbine Assembly
0-1
A11717-00
Support Rod
1-2
A13535-00
Fluid Tube Assembly
0-1
75911-00
Fiber Optic Transmitter Assembly
1
A13542-00
Fiber Optic Cable Assembly
0-1
77367-00
Valve Seat Assembly
3-5
A11252-01
Tubing, FEP (Cup Wash)
50 ft. (20 meters)
EMF-203-04
Front Ferrule, 1/4 O.D. Tubing, Fluid Coil
0-2
EMF-202-04
Back Ferrule, 1/4 O.D. Tubing, Fluid Coil
0-2
78278-00
Nut, Fiber Optic Transmitter
0-1
78949-00
Fitting, Fluid Coil
3-5
77516-01 Collet
1
79001-30
O-ring, Solvent Proof
1
79001-07
O-ring, Solvent Proof
1
79001-14
O-ring, Solvent Proof
2
79001-38
O-ring, Solvent Proof
2
79001-09
O-ring, Solvent Proof
1
79001-39
O-ring, Solvent Proof
1
79001-40
O-ring, Solvent Proof
3
79001-41
O-ring, Solvent Proof
0-1
79001-42
O-ring, Solvent Proof
1
79001-44
O-ring, Solvent Proof
1
LSOR0005-18
O-ring, Encapsulated
1
79010-00
Cascade Assembly
1
7959-24C Screw
4-6
A13437-00
Set Screw (F.O. and LV cables)
3
A11276-00
Fitting, Solvent (Cup Wash)
1-2
A11305-00
Lower Ferrule (Black- Cup Wash)
3-4
A11534-01
O-ring Kit (Turbine- Exterior)
1
A12253-00
Set Screw (Shape Air Manifolds)
1-2
A13328-00
Screw (Turbine Exhaust)
1-2
A13325-00
Diaphragm (Turbine Exhaust)
1-2
A12821-00
Cup Wash Ferrule (White)
3-4
A12822-00
Cup Wash Fitting
1-2
78949-00
Fluid Valve Assembly
3-5
Select Option Below- Fluid Tip Size
A11240-01
.7mm (.028”)
0-1
A11240-02
.9mm (.035”)
0-1
A11240-03
1.1mm (.043”)
0-1
A11240-04
1.2mm (.047”)
0-1
RMA-560 Single/Dual Purge Direct Charge - Parts Identification
Ransburg
LN-9278-13
92
