RMA-560 Assembly
RMA-560 SINGLE/DUAL PURGE DIRECT CHARGE ASSEMBLY
Item
Description
Qty
Part #
6
5
79001-14
O-RING, SOLVENT PROOF
7
1
“E”
SPINDLE
8
1
75911-00
ASS’Y, FIBER OPTIC TRANSMITTER
16
1
79001-42
O-RING, SOLVENT PROOF
32
1
“F”
FLUID COIL
36
1
79010-00
ASS’Y. CASCADE HP404
38
8
7683-16C
SCREW 1/4-20 STAINLESS STEEL
42
1
“A”
SHAPING AIR KIT
44
1
“B”
BELL CUP ASSEMBLY
48
1
“C”
RING, QUICK DISCONNECT
51
2
A11276-00
FITTING, SOLVENT
52
2
A11305-00
LOWER FERRULE, SOLVENT
58
5
A11717-00
ROD, SUPPORT (RMA-303 DUAL PURGE)
59
1
“D”
ASS’Y., VALVE MANIFOLD, RMA SINGLE /DUAL PURGE
68
1
A13424-00
KNUCKLE ASSEMBLY (WITH HV SPRING)
69
1
79001-30
O-RING, SOLVENT PROOF
70
1
77516-01
COLLET
71
1
A13322-00
EXHAUST TUBE
72
2
78449-00
FITTING, FLUID
73
2
EMF-202-04
FERRULE, BACK 1/4” TUBE
74
2
EMF-203-04
FERRULE, FRONT 1/4” TUBE
75
1
A13396-00
CUP WASH SPLITTER
76
1
A13430-00
REAR PLATE ASSEMBLY (SINGLE/DUAL PURGE)
77
10
79001-07
O-RING, SOLVENT PROOF
78
5
77508-00
AIRBOLT, MACHINED
79
1
A13412-00
BREAK AWAY RING (SINGLE/ DUAL PURGE)
80
5
A12822-00
CUP WASH FERRULE
81
5
A12821-00
CUP WASH FITTING
82
39 1/4” A11252-01
TUBING, FEP, 3/32 O.D. X 1/16 I.D.
89
1
“J”
SHROUD
90
1
A11226-00
RETAINER, FLUID TUBE
91
1
“G”
FLUID TIP
93
1
79001-40
O-RING, SOLVENT PROOF
94
1
79001-41
O-RING, SOLVENT PROOF
95
1
79001-44
O-RING, SOLVENT PROOF
96
1
A13535-00
FLUID TUBE ASSEMBLY
97
1
79001-22
O-RING, SOLVENT PROOF
1
6
8
2
5
9
7
10
RMA-560 Single/Dual Purge Direct Charge - Parts Identification
Ransburg
LN-9278-13
81
