NOTE
† Turbine air (TA) to be supplied at a
maximum length of 6 Ft. User or Inte-
grator must increase to 12mm OD tube
after 6 Ft.
TABLE A - (TUBING SELECTION)
Dash # Description “G” Qty
00 No Tubing None None None None None None None None None None None None
01 Single Purge 0 0 42 ft. 42 ft. 42 ft. 42 ft. 42 ft. 6 ft. 42 ft.x3 42 ft. 42 ft. 42 ft.x2
02 Dual Purge 42 ft. 42 ft. 42 ft.x2 42 ft. 42 ft. 42 ft. 42 ft. 6 ft. 42 ft.x4 42 ft. 42 ft. 42 ft.x2
“O” Qty “Q” Qty “T” Qty “U” Qty “V” Qty “W” Qty “X” Qty “Y” Qty “Z” Qty “AA” Qty “AB” Qty
TABLE B - (SINGLE/DUAL PURGE FITTING/RECEIVER SELECTION)
Dash # Description “D” Qty
01 Single Purge 22 1 4 4 4 3 2 1 1 1 2 4 4
02 Dual Purge 28 0 6 6 6 4 4 3 2 0 0 4 4
“E” Qty “F” Qty “H” Qty “J” Qty “K” Qty “L” Qty “M” Qty “P” Qty “R” Qty “AC” “AD” “S” Qty
TABLE C - FIBER OPTIC CABLE LENGTH
Dash # Description “C”
00 FIBER OPTIC CABLE (NOT INCLUDED) N/A
01 3 FT. LONG, FIBER OPTIC CABLE A12409-01
02 6 FT. LONG FIBER OPTIC CABLE A12409-02
03 10 FT. LONG FIBER OPTIC CABLE A12409-03
04 15 FT. LONG FIBER OPTIC CABLE A12409-04
05 25 FT. LONG FIBER OPTIC CABLE A12409-05
06 40 FT. LONG FIBER OPTIC CABLE A12409-06
07 50 FT. LONG FIBER OPTIC CABLE A12409-07
08 65 FT. LONG FIBER OPTIC CABLE A12409-08
09 75 FT. LONG FIBER OPTIC CABLE A12409-09
10 100 FT. LONG FIBER OPTIC CABLE A12409-10
RMA-560 Single/Dual Purge Direct Charge - Parts Identification
Ransburg
LN-9278-13 89
