Bell Cup Parts Breakdown Bell Cup Part Number / Serial Number
A11968-00 30MM TITANIUM, SERRATED (TIS) A11964-00 A11954-00 (WHITE COLOR)
A11968-01 30MM ALUMINUM, SERRATED (ALS) A11964-01 A11954-00 (WHITE COLOR)
A12900-00 65MM TITANIUM, SERRATED (TISF) A12886-00 A12071-00 (BLACK COLOR)
A12900-01 65MM TITANIUM, NON-SERRATED (TIF) A12886-01 A12071-00 (BLACK COLOR)
A12900-02 65MM TITANIUM, SERRATED/LONG LIFE A12886-00 A13004-00 (TITANIUM TOP)
SPLASH PLATE (TISF)
A12900-03 65MM TITANIUM, NON-SERRATED/LONG LIFE A12886-01 A13004-00 (TITANIUM TOP)
SPLASH PLATE (TIF)
A12900-04 65MM ALUMINUM, SERRATED, PLASTIC A12886-02 A12071-00 (BLACK COLOR)
SPLASH PLATE (ALSF)
A12900-05 65MM ALUMINUM, NON-SERRATED, PLASTIC A12886-03 A12071-00 (BLACK COLOR)
SPLASH PLATE (ALF)
A12900-06 65MM ALUMINUM, SERRATED, BLACK A13541-00 A12071-00 (BLACK COLOR)
COATED, PLASTIC SPLASH PLATE (ALSCF)
A12900-07 65MM ALUMINUM, NON-SERRATED, BLACK A13541-01 A12071-00 (BLACK COLOR)
COATED, PLATIC SPLASH PLATE (ALCF)
A13114-00 55MM TITANIUM, SERRATED (TISF) FOR A13113-00 A11269-00 (WHITE COLOR)
55MM DUAL FLEX SHAPE AIR KIT
A13114-01 55MM TITANIUM, NON-SERRATED (TIF) FOR A13113-01 A11269-00 (WHITE COLOR)
55MM DUAL FLEX SHAPE AIR KIT
TYPICAL BELL CUP PARTS BREAKDOWN
Complete
Part #
Description
Cup Only
Part #
Splash Plate
Part #
RMA-560 Single/Dual Purge Direct Charge - Parts Identification
