SPECIFICATIONS
Electrical:
Power Supply Type: MicroPak
Charging Method:
Direct
Output Voltage: 30-100 kV Variable
(100 kV Maximum)
Output Current: 125 µA
Turbine Speed
Control: Atomizer Module
Part Spray Ability: Determine spray ability of
part to be coated using
Test Equipment (76652)
(Paint Conductivity Meter)
Shaping Air #1 Variable (See “Pressure
(SAI) Supply: Flow Data Charts” in the
“Introduction” section)
Shaping Air #2 Variable (See “Pressure
(SAO) Supply: Flow Data Charts” in the
“Introduction” section)
Brake Air Supply
(Nominal): 60-100 psig (414-689 kPa)
Maximum Fluid Pressure Supply:
Paint: 200 psi (1379 kPa)
Solvent: 150 psi (1035 kPa)
Fluid Flow Rate: 25-800 cc/min.
(See exclusion below)
30mm Bell Cup Max. Flow Rate: 300 cc/
min. at 80,000 rpm
55mm Bell Cup Max Flow Rate: 500 cc/
min. at 80,000 rpm
Max. Flow Rate: 800 cc/
min at 70,000 rpm
65mm Bell Cup Max. Flow Rate: 500 cc/
min at 80,000 rpm
Max. Flow Rate: 800 cc/
min. at 70,000 rpm
Bell Cup Cleaning Time
(Internal/External): 2.7 sec. (approx.)
Color Change Time: Dependent on system
configuration, fluid pressures,
fluid viscosity,fluid line
lengths, etc.
Speed Readout: Magnetic pick-up, unidirec-
tional fiber optic transmission
Atomizer
Replacement Time: Less than 5 min.
Bell Cup
Replacement Time: Less than 2 min.
Minimum Control Equipment
Requirements: (Versions listed or higher)
MicroPak LECU5004-11 (V.3.84)
Atomizer Module A11925-00 (V.0.4)
I/O Module A11435-00 (V.1.4)
(0.01V) (4-20 mA)
* Specifications and ratings based on testing at sea
level standard conditions.
Air Heater Recommendation:
An Air Heater is recommended for the turbine air
supply. See Air Heater and filteration recommenda-
tion later in this manual
Mechanical (Cont.)
:
Mechanical
:
Length: (See RMA-560 Tool Point, Center of
Gravity, and Envelope Dimension
(Single and Dual Flex) figure in the
“Introduction” section.)
Diameter: (See RMA-560 Tool Point, Center of
Gravity, and Envelope Dimensions
(Single and Dual Flex) figure in the
“Introduction” section.)
Approximate Weight (Dual Flex)
Atomizer Only: 12.77 lbs. (5.8 Kg) max.
Total Payload with Robot Plate (Dual Flex)
& Adapter: 15.57 lbs. (7.1 Kg) max.
Turbine Type: Air Bearing Impulse Drive
Turbine Air Supply: Variable (See “Pressure
Flow Data Charts” in the
“Introduction” section.)
Maximum/Minimum
Turbine Speed: Continuous 80K rpm max.
/20K rpm min. See excep-
tion at “Fluid Flow Rate”
Maximum Angular
Velocity for Turbine
(Robot Motion): 250 ° /sec.
Tubing Bundle
Max. Rotation: 450 ° in Either Direction
Bearing Air Supply
at the Applicator: 90 psig (±10 psi)
(Nominal): (621 kPa ±69 kPa) 2.9
SCFM (82 slpm)
