Weekly Maintenance (Prior to Start or End of
Production Week)
•
Monitor rotational speed of all belts at the
speed control. Investigate cause if abnor-
mal.
•
Monitor high voltage and current output indi-
cated on the MicroPak display. Investigate
cause if abnormal.
•
Check paint flow on all bells at minimum
and maximum specified settings by taking
beakered readings.
•
Check solvent flow by opening solvent valve
and taking a beakered reading (should be
within approx. 10% of target flow rate).
•
Paint residue found in the shaping air holes
is not acceptable and must be removed pri-
or to applicator use (see “Cleaning Shaping
Air Holes” in the “Maintenance” section).
•
Clean any paint on outer surface of front
and rear housing with a soft cloth damp-
ened with solvent. (See “Warning” on
avoiding the use of cleaning solvent con-
taining d-Limonene.)
•
Remove the front shroud and check for any
signs of solvent or paint leakage. Clean as
required as required.
•
Remove bell cup and soak in solvent for 1-2
hours. Clean with a soft brush as required.
Remove from cleaning solution and blow
dry before replacing.
•
With bearing air off, carefully inspect the
feed tube tip and clean any paint build-up
that has occurred on the feed tube tip. Us-
ing a pen light, determine if there is build-up
of paint in the motor shaft and/or around
the paint feed tube. If so, remove the motor
assembly following the disassembly proce-
dures and clean out the inside diameter of
the motor shaft using a tube brush and sol-
vent. Clean the outer surfaces of the feed
tube.
NOTE
Refer to the “Troubleshooting Guide”
in the “Maintenance” section for details
on determining the causes of low or no
high voltage at the bell cup.
NOTE
It may be necessary to remove the bell
cups for cleaning more frequently than
weekly. (See Note under “Daily Mainte-
nance” in the “Maintenance” section.)
•
Visually inspect for signs of fluid leaks
around fluid connections and manifold.
Correct problem and clean paint from all
components, including internal portion of
shroud.
•
Reinstall bell cup and front shroud, replace
cover on the outer housing. (Refer to “Dis-
assembly Procedures” in the “Maintenance”
section for definite instructions.)
•
Recheck bell cup tightness. Torque to 50-
70 lbs•in (5.65-7.91 Nm).
BELL CUP PREVENTIVE
MAINTENANCE
It is the user’s responsibility to ensure proper
maintenance of the atomizer bell at all times.
Bell cup failure due to inadequate cleaning or
handling will not be covered under the War-
ranty. The
“DO NOT” bullets (see “Operator/
Maintenance Warnings” in the “Maintenance”
section) listed are some examples of improper
handling which could adversely affect perfor-
mance or personnel safety and should not be
attempted for any reason.
