01 A11968-00 30MM TITANIUM, SERRATED (TIS)
02 A11968-01 30MM ALUMINUM, SERRATED (ALS)
03 A12900-00 65MM TITANIUM, SERRATED (TISF)
04 A12900-01 65MM TITANIUM, NON-SERRATED (TIF)
05 A12900-02 65MM TITANIUM SERRATED/LONG LIFE
SPLASH PLATE (TISF)
06 A12900-03 65MM TITANIUM NON-SERRATED/LONG
LIFE SPLASH PLATE (TIF)
07 A12900-04 65MM ALUMINUM, SERRATED, PLASTIC
SPLASH PLATE (ALSF)
08 A12900-05 65MM ALUMINUM, NON-SERRATED,
PLASTIC SPLASH PLATE (ALF)
09 A12900-06 65MM ALUMINUM, SERRATED, BLACK
COATED, PLASTIC SPLASH PLATE (ALSCF)
10 A12900-07 65MM ALUMINUM, NON SERRATED, BLACK
COATED, PLASTIC SPLASH PLATE (ALCF)
11 A13114-00 55MM TITANIUM, SERRATED (TISF) FOR
55MM DUAL FLEX SHAPE AIR KIT
12 A13114-01 55MM TITANIUM, NON-SERRATED (TIF)
FOR 55MM DUAL FLEX SHAPE AIR KIT
TABLE B - BELL CUP ASSEMBLY
Dash
No.
Description “B”
01 A13455-01 PLASTIC WITH SKIRT EXTENSION - WHITE
02 A11201-00 STAINLESS STEEL
TABLE C - MOUNTING RING
Dash No. Description “C”
Used With Shape Air Kit
A12874-03, A12874-04
A12874-03, A12874-04
A12874-05, A12874-06, A12874-08, A12874-09
A12874-05, A12874-06, A12874-08, A12874-09
A12874-05, A12874-06, A12874-08, A12874-09
A12874-05, A12874-06, A12874-08, A12874-09
A12874-05, A12874-06, A12874-08, A12874-09
A12874-05, A12874-06, A12874-08, A12874-09
A12874-05, A12874-06, A12874-08, A12874-09
A12874-05, A12874-06, A12874-08, A12874-09
A12874-12
A12874-12
01 A13440-00 SINGLE PURGE
02 A13540-01 DUAL PURGE
TABLE D - VALVE MANIFOLD ASSEMBLY
Dash No. Description “D”
RMA-560 Single/Dual Purge Direct Charge - Parts Identification
