Appendix D Parameters for
M O N I T O R I N G A N D D A T A
140
PowerSmart+ Advanced Power Quality Meter
Designat
ion
Description
%HD V2
V2/V23 Harmonic Distortions
2
V2 %HD01
H01 Harmonic distortion
V2 %HD02
H02 Harmonic distortion
…
...
V2 %HD50
H50 Harmonic distortion
%HD V3
V3/V31 Harmonic Distortions
2
V3 %HD01
H01 Harmonic distortion
V3 %HD02
H02 Harmonic distortion
…
...
V3 %HD50
H50 Harmonic distortion
%HD I1
I1 Harmonic Distortions
I1 %HD01
H01 Harmonic distortion
I1 %HD02
H02 Harmonic distortion
…
...
I1 %HD50
H50 Harmonic distortion
%HD I2
I2 Harmonic Distortions
I2 %HD01
H01 Harmonic distortion
I2 %HD02
H02 Harmonic distortion
…
...
I2 %HD50
H50 Harmonic distortion
%HD I3
I3 Harmonic Distortions
I3 %HD01
H01 Harmonic distortion
I3 %HD02
H02 Harmonic distortion
…
...
I3 %HD50
H50 Harmonic distortion
ANG V1
V1/V12 Harmonic Angles
2
V1 H01 ANG
H01 Harmonic angle
V1 H02 ANG
H02 Harmonic angle
…
...
V1 H50 ANG
H50 Harmonic angle
ANG V2
V2/V23 Harmonic Angles
2
V2 H01 ANG
H01 Harmonic angle
V2 H02 ANG
H02 Harmonic angle
…
...
V2 H50 ANG
H50 Harmonic angle
ANG V3
V3/V31 Harmonic Angles
2
V3 H01 ANG
H01 Harmonic angle
V3 H02 ANG
H02 Harmonic angle
…
...
V3 H50 ANG
H50 Harmonic angle
ANG I1
I1 Harmonic Angles
I1 H01 ANG
H01 Harmonic angle
I1 H02 ANG
H02 Harmonic angle
…
...
I1 H50 ANG
H50 Harmonic angle
ANG I2
I2 Harmonic Angles
I2 H01 ANG
H01 Harmonic angle
I2 H02 ANG
H02 Harmonic angle
…
...
I2 H50 ANG
H50 Harmonic angle
ANG I3
I3 Harmonic Angles
I3 H01 ANG
H01 Harmonic angle
I3 H02 ANG
H02 Harmonic angle
…
...
I3 H50 ANG
H50 Harmonic angle
H1 PHASE
Fundamental (H01) Phase Values
V1 H01
V1/V12 Voltage
2
V2 H01
V2/V23 Voltage
2
V3 H01
V3/V31 Voltage
2
I1 H01
I1 Current
I2 H01
I2 Current
I3 H01
I3 Current
kW L1 H01
kW L1
