PktGraph
Page 5-31
PktGraph
This menu provides real-time packet statistics, in a graph format, on a
selected port.
Table 5-22 describes each field in the PktGraph menu.
∆
Note: For instructions on using this menu, see “View-
ing Packet Statistics (Graph Format)” on page 4-34.
Table 5-22 PktGraph Menu
Field Description
Seconds Drop-down menu; specifies the amount of time (in
seconds) that the port is polled for information.
Statistics Drop-down menu; determines the object for which
statistics are gathered.
Note: For a description of each object, see “Objects”
on page 5-30.
Average per sec-
ond Displays the average number of occurrences since
opening or resetting the screen.
Reset Statistics Button; resets the counters to zero.
Peak per second Displays the largest number of occurrences since
opening or resetting the screen.
Count-per-second
display Displays the amount of counts (per second) displayed
on the graph.
Note: To control the count-per-second display, use
the scroll bar on the right side of the graph (scroll up
to increase the count-per-second; scroll down to
decrease it).
Objects For a description of each object, see “Objects” on
page 5-30.
