Viewing Statistics
Page 4-31
3
Open the Sampling Interval drop-down menu and
select the number of seconds to poll for statistics.
Statistics are automatically gathered at the selected interval
in the following columns:
❏ Curr — (current) the number of occurrences each
second.
❏ Peak — the largest number of occurrences since
opening or resetting the screen.
❏ Avg — (average) the average number of occurrences
since opening or resetting the screen.
❏ Total — the total number of occurrences since open-
ing or resetting the screen.
4
Click Reset to reset the counters to zero.
Viewing Counter Statistics (Graph Format)
To view counter statistics in a graph format:
1
Select a port for which statistics are to be gathered by
clicking on it once on the front-panel image.
▲ Important: Statistics can be viewed at the port-
level only.
2
Click Graph.
Counter statistics appear for the selected port, similar to
Figure 4-19.
