Page 5-1
5
Menus
This chapter describes each management menu on the IntraStack 6000
Series’s Device Page.
The table below provides a brief description of each menu; the sections
that follow explain each menu in detail.
Table 5-1 Device Page Menu Descriptions
Menu Description
Configuration Title for the submenus listed below it; this menu cannot be
selected. See “Configuration” on page 5-4.
Identify Allows you to view and configure device identification
information. See “Identify” on page 5-4.
Agent Allows you to view agent information. Also allows you to
configure the device’s image load mode, remote boot infor-
mation, and out-of-band dial string and baud rate. See
“Agent” on page 5-5.
IPAgent Allows you to view and configure the IP address, default
gateway, and boot server address for the device. Also
allows you to set the Telnet idle time-out period. See
“IPAgent” on page 5-7.
swAgentSW Allows you to view and configure the information needed
for downloading a new image file or configuration file. Also
allows you to enable or disable the Spanning Tree Protocol.
See “swAgentSW” on page 5-9.
swAgentHW Allows you to view hardware information on the device’s
SNMP agent (such as DRAM and EEPROM size). See
“swAgentHW” on page 5-11.
swBasic Allows you to view basic information (such as the back-
plane type and group capacity) on the device or a particular
group. See “swBasic” on page 5-12.
