Accessing the Device
Page 3-6
Menu Components
The menus on the IntraStack 6000 Series Device Page provide access to
the different management options supported by the Personality Module.
Tables
Some menus contain tables with information that is configurable
directly on-screen from your Web browser while others contain informa-
tion that is read-only. The following tables describe how to recognize
configurable and read-only information.
Configurable Information
Read-only Information
Table Columns
Some menus contain table columns that can be resized to fit the width
of your screen. To resize a table column, place the mouse pointer on a
column title’s left or right side (until a double arrow appears) and drag
the column to the left or to the right, as desired.
Buttons
Some menus contain buttons which allow you to edit/and or update the
page.
Menu item Action
Drop-down menu Select from an available option.
White-colored fields Type information.
Menu item Action
Green- or gray-colored fields None; field cannot be edited.
Button Action
Apply Applies any changes made to the device.
Refresh Updates the table with the latest information.
Modify Modifies a selected entry.
Add Adds an entry into the table.
