PortInfo
Page 5-21
PortInfo
This menu displays read-only port information (such as the port’s type,
auto-negotiation status, link status, speed, and duplex mode) for each
port within the device.
Table 5-15 describes each field in the PortInfo menu.
∆
Note: For instructions on using this menu, see “View-
ing Port Parameters” on page 4-10.
Table 5-15 PortInfo Menu
Field Description
GrpIndex Read-only field; displays the number of the group to
which the port belongs.
Index Read-only field; displays the number of the port.
Port Type Read-only field; displays the type of port.
❏
RJ45 — regular TX port
❏
MII_RJ45 — expansion port TX
❏
MII_Empty — expansion port empty
❏
MII — expansion port, type unknown
❏
MII_FOIL — expansion port FX
❏
FOIL — regular FX port
AutoNeg Read-only field; displays the auto-negotiation ability
of the port.
❏
with — the port is capable of auto-negotiation
❏
without — the port is not capable of auto-
negotiation
Link Read-only field; displays the link status of the port.
Port Speed Read-only field; displays the working speed of the
port.
❏
10Mbps — the port is operating at 10Mbps
❏
100Mbps — the port is operating at 100Mbps.
Port Duplex Read-only field; displays the working mode of the
port.
❏
Half-Duplex — the port is operating in half-
duplex mode.
❏
Full Duplex — the port is operating in full-
duplex mode.
