Menus
Page 5-30
PktTable
This menu provides real-time packet statistics, in a table format, on a
selected port.
Table 5-21 describes each field in the PktTable menu.
∆
Note: For instructions on using this menu, see “View-
ing Packet Statistics (Table Format)” on page 4-33.
Table 5-21 PktTable Menu
Field Description
Sampling Interval Configurable field; allows you to set the amount of
time (in seconds) that the port is polled for informa-
tion.
Reset Button; resets the counters to zero in the table.
Objects ❏
etherStatsPkts64Octets — the total number of
packets (including error packets) received that
were 64 octets in length (excluding framing
bits but including FCS octets).
❏
etherStatsPkts65to127Octets — the total
number of packets (including error packets)
received that were between 65 and 127 octets
in length inclusive (excluding framing bits but
including FCS octets).
❏
etherStatsPkts128to255Octets — the total
number of packets (including error packets)
received that were between 128 and 255
octets in length inclusive (excluding framing
bits but including FCS octets).
❏
etherStatsPkts256to511Octets — the total
number of packets (including error packets)
received that were between 256 and 511
octets in length inclusive (excluding framing
bits but including FCS octets).
❏
etherStatsPkts512to1023Octets — the total
number of packets (including error packets)
received that were between 512 and 1023
octets in length inclusive (excluding framing
bits but including FCS octets).
❏
etherStatsPkts1024to1518Octets — the total
number of packets (including error packets)
received that were between 1024 and 1518
octets in length inclusive (excluding framing
bits but including FCS octets).
