Micromod MOD: 30ML Controller Operation and Maintenance Training Manual User Manual
Page 56
Training Manual
MOD 30ML Diagnostics Lab
4 - 8
7
Press the SCROLL key ONCE.
The PID setpoint will be shown on line 6 and the
text “SP” on line 5.
8.
Press the SCROLL key one more
time and wait for a few seconds.
The runtime PID display will disappear and
FAILURE
will be displayed on line 1 with an
audible continuous alarm.
At this point, you cannot operate the PID loop or
use the controller.
This is an indication that the controller is in
SHUTDOWN mode.
