Micromod MOD: 30ML Controller Operation and Maintenance Training Manual User Manual
Page 54
Training Manual
MOD 30ML Diagnostics Lab
4 - 6
6
Press the DOWN key once.
CLR Q
is displayed on line 2.
7
Press the UP arrow.
YES will be displayed.
8 Press
ENT
(SCROLL key).
The Events queue will be cleared and line 6 will
display NO again.
9
Press the TAG key.
The DEVICE page will be displayed.
10
Pres the TAG key again.
Your runtime display will be displayed.
