MODCELL Multiloop Processor
PRODUCT DESCRIPTION
1.4.4 2013A Thermocouple Input Module (with upscale burnout detection)
The thermocouple input module is identical to the ±100 mV voltage input module except
for the addition of upscale burnout detection circuitry. Thermocouple types allowed are: B,
E, J, K, N, S, or T. A cold junction compensator (CJC) module is used to sense the
temperature at the terminal block for all thermocouples. This module uses the
Thermocouple Input Module (TIM) Block for configuration of input parameters.
TIM
Catalog Number Description for 2013A
BASE NUMBER
2013A Thermocouple Input (with upscale burnout detection)
UNUSED Z Unused Character
ELECTRICAL CODE 10 General Purpose, standard
6
7
3
4
5
2
1
INPUT RANGE 10 ±100 mV
ISOLATION 1 Isolated
MODEL A 1st Design Level
B 2nd Design Level
Sample Number 2013AZ10101A
1.4.5 2003A Current Output Module
The current output module provides an isolated 0-20 mA or 4-20 mA current output. An
internal A/D converter reads back the output value to check for open outputs or broken
wires. This module uses the Analog Output Module (AOM) Block for configuration of
output parameters.
AOM
Catalog Number Description for 2003A
BASE NUMBER
2003A Current Output Module
UNUSED Z Unused Character
ELECTRICAL CODE 10 General Purpose, standard
6
7
3
4
5
2
1
OUTPUT RANGE 10 4 – 20 mA
ISOLATION 1 Isolated
MODEL A Design Level
Sample Number 2003AZ10101A
