3.4.1.6 SAMPLE HAND HELD CONFIGURER COMMANDS
The following table provides a sample of typical Hand Held Configurer Display (D ), Put (P ), and
Memory Transfer (T ) commands.
Key Entries Displayed Data Result
D B021 D B021 XXX Displays contents of B021.
D N D B022 XXX Displays contents of B022.
D D B022 XXX B022 contents still displayed.
P C256 200 P C256 200 Alters contents of C256 to 200.
P 150 P C256 150 Alters contents of C256 to 150.
P N 200 P C257 200 Alters contents of C257 to 200.
T MEMORY TRANSFER
F1 - TO CONTROLLER
F2 - FROM CONTROLLER
F
F
F
TRANSFER FINISHED
Displays memory transfer query
to either send database
information (or analog
constants) to the instrument, or
receive database information
(or analog constants) from the
instrument.
Note: XXX = Displayed characters from addressed datapoint.
