Micromod Micro-DCI: 53ML5100A LOADING STATION User Manual
Page 25
Figure 3-2. Display 1 - Dual Channel Manual Loader (Chs. 1 & 2)
Showing Channel 2 Selected Using the 3 Push Button
Figure 3-3. Display 2 - Single Channel Manual Loader (Ch. 1 only)
ANO0 Tag Name (A244)
ANO0 Digital Readout
ANO0 Engineering Units
ANO0 Output Bar
ANO0 Scale Values
CHANNEL 1
ANO0 Tag Name (A244)
ANO0 Digital Readout
ANO0 Engineering Units
ANO0 Output Bar
ANO0 Scale Values
ANO1 Tag Name (A245)
ANO1 Digital Readout
ANO1 Engineering Units
ANO1 Output Bar
ANO1 Scale Values
CHANNEL 1
Heavy Border Indicates
Active Window
CHANNEL 2
3 Push Button
53ML5100 Manual Loading Station
3-2
