Page 68

2. Connect the FLEXMAP 3D
®
instrument and all necessary peripheral devices to the PC.
FIGURE 24.
Back of PC
1.
Monitor Plug
5.
Monitor Plug (Touchscreen monitors only)
2.
FLEXMAP 3D Communications Plug (USB
type A )
6.
Stereo Speaker Power (USB connection)
3.
Mouse Plug
7.
Stereo Speaker Audio Connection
4.
Barcode Scanner Plug
8.
Power Inlet
FIGURE 25.
Back of FlexMAP 3D Instrument
Luminex
®
FLEXMAP 3D
®
Hardware User Manual
58
For research use only. Not for use
in diagnostic procedures.
