FIGURE 9.

Front of the FLEXMAP 3D

®

Instrument

1

Left door, with access to sheath filter and door ventilation filter

2

Right door, with access to syringe pumps, door ventilation filter, and sample probe

Sample Probe

A stainless steel sample probe acquires the sample. See the "Sample Probe" image below.

WARNING:

Avoid contact with moving parts.

Cheminert

®

Fitting

This fitting attaches the sample probe to the sample tubing. Disconnect this fitting when you
remove the sample probe. See the "Sample Probe" figure below.

WARNING:

Wear appropriate personal protective equipment when handling
parts that come into contact with potentially biohazardous
samples.
