View A

Right front door, viewed from inside

2 Filter Clamp

View B

Left front door, viewed from inside

3 Incised Arrow

1

Filter

Annual Maintenance

Annual maintenance requires replacing the sheath filter.

To replace the Luminex

®

FLEXMAP 3D

®

instrument sheath filter:

1. Turn off the FLEXMAP 3D

®

instrument and unplug the power cord.

2. Open the left door on the FLEXMAP 3D

®

instrument and locate the sheath filter on the

front of the fluidics bay.

3. Disconnect the filter by pushing down on the metal clamps at each quick-disconnect

point.

NOTE: For information on the location of the disconnection clamps,

reference the "Front of Fluidics Bay (Inside Left Door)" image below.

4. Connect the new sheath filter, matching up the color-coded fittings. The arrow on the

sheath filter should be pointing up.

5. Close the left door.
