MKVI Mix Meter System Operations Manual
Rev. 08/2013 Page | 58
Mixer Tubes:
Mixer tubes will only require replacement if partial or full
gelation/sedimentation has occurred in the injection head. They
cannot be repaired and must be replaced.
To replace, first remove Mould Pressure Guard (MPG) signal pipes
and remove mixer shroud from head.
Remove mixer tube from inside shroud. Lightly grease new mixer
tube/shroud threads with silicon grease, ensure shroud internal O-ring
(0749) is in position and replace in mixer shroud.
Re-attach to mixer head and reconnect MPG pipes. (Blue pipe
nearest to mixer tube)
