Magnum Venus Plastech Flex Molding Process MKVI Mix User Manual
Page 46
MKVI Mix Meter System Operations Manual
Rev. 08/2013
Page | 46
Megaject Auto Head
– 1:1 configuration with CAV attached:
RAV (Resin Auto Valve)
Start / Air Interlock Signals
Catalyst / Hardener supply &
return hoses
CAV (Catalyst Auto Valve)
Resin / Hardener Supply Hoses
Start / Air Interlock Signals
–
for the CAV
RAV (Resin Auto Valve)
Flush Supply
Mixer Assembly
MPG (Mould Pressure
Guard)
Resin / Hardener
Supply Hoses
Start / Air Interlock Signals
