Megaject auto head – Magnum Venus Plastech Flex Molding Process MKVI Mix User Manual
Page 45
MKVI Mix Meter System Operations Manual
Rev. 08/2013
Page | 45
Megaject Auto Head:
RAV (Resin Auto Valve)
Start Signal from cabinet
Catalyst / Hardener supply &
return hoses
CAV (Catalyst Auto Valve)
Resin Supply Hose
Megaject Auto Head
– Polyester or CAV
configuration
Start / Air Interlock Signals
–
for the CAV
Start / Air Interlock Signal
–
for the CAV
