Resin Auto Valve
– RAV:
RAV (Resin Auto Valve)
Start Signal from cabinet
Resin Supply Hose
M5 x 110mm Clamp
Plate retaining Bolts
Remove 2 M6 Bolts to
split Head Blocks
0728 & 0727
Megaject Auto Head
– CAV configuration
Megaject Auto Head
– 1:1 Configuration with optional CAV
M5 x 110mm Clamp
Plate retaining Bolts
Start / Air Interlock Signal
configured for Dual RAV -
1:1 materials. When
configured for CAV (lower
ratio materials) this will
connect to the CAV signal
ports.
RAV (Resin Auto Valve)
RAV (Resin Auto Valve)
CAV (Catalyst Auto Valve)
Start / Air Interlock Signals
–
for the CAV
