Unit overview - megaject auto head – Magnum Venus Plastech Flex Molding Process MKVI Mix User Manual
Page 18
MKVI Mix Meter System Operations Manual
Rev. 08/2013
Page | 18
Unit Overview - Megaject Auto Head:
RAV (Resin Auto Valve)
Start Signal Circuit
Catalyst Supply & return hoses
Mixer & Mixer Housing
CAV (Catalyst Auto Valve)
MPG Signal and Supply
MPG Valve (Mold Pressure Guard)
Resin Supply Hose
RAV (Resin Auto Valve)
Resin / Hardener Supply Hoses
CAV Air supply connections
Polyester Head
Configuration
1:1 Head Configuration
with CAV option attached
