SP3850 Flow Computer
52
Cal Therm: 100 Ohms
Therm TB1-6 to TB1-4
Cal Therm: 100 Ohms
0 CALIBRATING ——
Cal Therm: 100 Ohms
*** DONE ***
Cal Therm: 100 Ohms
Therm TB1-6 to TB1-4
Advance to
Cal Therm: Open
To Calibrate: Place a 100 ohm 0.1% resistor
between TB1-6 and TB1-4. Press enter to
calibrate.
This message is displayed during calibration.
This message is displayed when the
calibration is finished.
The display will automatically return to the Cal
Therm: 100 Ohms top-level menu. Press the
Down arrow key to advance to the Thermistor
Open calibration.
8.2.10
Cal Therm: 100
Ohms
Submenu Group
ENTER
STOP
Cal Therm: Open
Therm TB1-6 to TB1-4
Cal Therm: Open
0 CALIBRATING ——
Cal Therm: Open
*** DONE ***
Cal Therm: Open
Therm TB1-6 to TB1-4
Advance to
Calibrate Aux2: 0V
To Calibrate: Remove the 100
Ω 0.1% resistor
from TB1-6 and TB1-4 and leave open. Press
enter to calibrate.
This message is displayed during calibration.
This message is displayed when the
calibration is finished.
The display will automatically return to the Cal
Therm Open top-level menu. Press the Down
arrow key to advance to the Aux2: 0V
calibration.
8.2.11
Cal Therm: Open
Submenu Group
ENTER
STOP
