SP3850 Flow Computer
28
Sub-menus Display Notes
If StRo selected,
Enter the desired St/ Ro pair (in ascending
order) for each point in the Linearization Table.
(channel A)
NOTE: Enter 0 for Ro value of any point (other
than RoA01) to exit the routine and use
the values entered up to that point.
Enter the desired St/ Ro pair (in ascending
order) for each point in the Linearization Table.
(channel B)
NOTE: Enter 0 for Ro value of any point (other
than RoB01) to exit the routine and use
the values entered up to that point.
Enter the desired volumetric Low Rate Alarm.
This will trigger an alarm message if alarm
conditions occur. The relays are not affected.
Enter the desired volumetric High Rate Alarm.
This will trigger an alarm message if alarm
conditions occur. The relays are not affected.
If StRo selected, Enter the expansion
coefficient for the meter housing.
If StRo selected, Enter the calibration
temperature.
If UVC or StRo selected, Enter the density of
water at 4
° C.
LINEAR TABLE KA
RoA01:########
LINEAR TABLE KA
StA01:#######
LINEAR TABLE KB
RoB01:########
LINEAR TABLE KB
StB01:#######
LOW FLOW RATE ALARM
####### gal/s
HIGH FLOW RATE ALARM
####### gal/s
METER EXPAN [xe - 6]
0 ppm/f
CALIBRATION TEMPERATURE
70 F
H2O DENSITY AT 4 DEG C
8.34519 lbs/g
Advance To
SETUP AUX1 INPUT
Through 40 Points
ENTER
ENTER
Through 40 Points
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
6.3.8
SETUP
FLOW INPUT
(continued)
