SP3850 Flow Computer

CALL ON ERROR/ALARM
No Yes

CALL OUT PHONE #
0

NUMBER OF REDIALS
0

HANGUP IF 2MIN INACT
No Yes

Advance To

SETUP DATALOG/PRINT

Config Select_list

OUTPUT FORMAT
Printer Term Dbase

PAGE LENGTH [99 max]
99

TOP MARGIN [99 max]
3

DATALOG ONLY
No Yes

PRINT TIME HH:MM:SS
00:00:00

PRINT INTERVAL
00:00:00

ENABLE PRINT KEY
NO YES

CLEAR TOTAL IF PRINT
NO YES

PRINT END OF BATCH
NO YES

Advance To

SETUP DATALOG/PRINT

(Select_list)

ENTER

Select "Yes" to have the unit perform a Call
Out transmission upon error/alarm condition.

Call Out Phone Number to be dialed for "Call
Out Time" or "Print On Error/Alarm". (Up to 20
digits with "." used to pause between digits)

Enter the number of redials to be performed
on call out time if busy or no answer (error/
alarm tries until connected).

Select "Yes" to perform hangup if there is
inactivity for more than 2 minutes.

Press Enter to setup the Datalog/Print
information.

Select Config to configure the Datalog/Print
information.

Select the type of Output Format.

Enter the desired Page Length.
If Printer selected above.

Enter the desired Top Margin.
If Printer selected above.

Select Yes to record events to the datalogger
only. Events will not be sent to the serial port.

Enter Print Time, printer will print at this time
every day. Enter 00:00:00 to inhibit print time.

Enter Print Interval,
Enter 00:00:00 to inhibit print interval..

Select YES to enable Print Key.
Select NO to disable Print Key

Select Yes to clear the total after printing.

Batch mode only.
Select Yes to print at end of batch.

6.3.21
SETUP
DATALOG/PRINT
(Configure)

Sub-menus

Display

Notes

6.3.20
SERIAL USAGE
(Modem Options)
(continued)

ENTER
