SP3850 Flow Computer
6.3.9
SETUP AUX1 INPUT SETUP AUX1 INPUT
AUX1 INPUT TYPE
None
Temp
AUX1 SIGNAL TYPE
Therm Current RTD
INPUT SIGNAL RANGE
4-20mA 0-20mA
AUX1 LOW SCALE
###### F
AUX1 FULL SCALE
###### F
OFFSET TEMPERATURE
###### F
LOW TEMP TOT LIMIT
###### F
HIGH TEMP TOT LIMIT
###### F
DENS EXTRACT METHOD
Therm_Coef API-2540
Advance To
SETUP AUX2 INPUT
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
Press ENTER to begin setup of the Auxiliary 1
Input.
Select Temperature to set the Auxiliary 1 Input
for Temperature inputs.
Choose Temperature Signal Type. (If RTD
selected, AUX2 will not be available for Density
or Pressure)
If Current selected,
Choose desired Current Range. Skip if
Thermistor or RTD.
Enter the low temperature scale corresponding
to the low temperature signal. Skip if
Thermistor or RTD.
Enter the high temperature scale
corresponding to the high temperature signal.
Skip if Thermistor or RTD.
Enter the offset temperature.
Enter the Lowest temperature for which
totalization should occur.
Enter the Highest temperature for which
totalization should occur.
Enter the Density Extract Method to be used.*
ENTER
Sub-menus Display Notes
ENTER
* Only appears if RTD selected.
