SP3850 Flow Computer
32
6.3.13
SETUP
ANALOG OUTPUT
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
SETUP ANALOG OUTPUT
ANALOG OUTPUT USAGE
Rte Tot Tmp Den Pres
ANALOG OUT FLOW TYPE
Vol CVol/Mass
ANALOG OUTPUT RANGE
4-20mA 0-20mA
LS ANALOG OUTPUT
####### gal/m
FS ANALOG OUT 20mA
####### gal/m
ANALOG OUT DAMPING
0.0
Advance To
SETUP RELAYS
Press ENTER when Analog is flashing to
setup the Analog Output.
Select the desired Analog Output Usage.
Only if Rate selected & Flow EQ. = Mass, Cor/Vol
Select the desired Analog Output Flow.
Select the desired current range for the Analog
Output.
Enter desired Analog Output Low Scale Value.
NOTE: Units label will correspond with output
usage type selected.
Enter desired Analog Output Full Scale Value.
Enter the desired Analog Output Damping
Constant. Increase value to slow response
time and eliminate "bounce".
ENTER
6.3.12
SETUP
PULSE OUTPUT Press ENTER at this prompt to setup the
Pulse Output.
Select the desired Pulse Output Usage.
Select the desired Pulse Width for the Pulse
Output.
Enter the desired Pulse Value for the Pulse
Output (Units per Pulse).
ENTER
ENTER
ENTER
ENTER
SETUP PULSE OUTPUT
PULSE OUTPUT USAGE
Off Vol CVol/Mass
PULSE WIDTH
10mS 100mS
PULSE VALUE
####### gal/P
Advance To
SETUP ANALOG OUTPUT
Sub-menus Display Notes
