SP3850 Flow Computer
24
ENTER
ENTER
ENTER
ENTER
Sub-menus Display Notes
Press ENTER to enter Select Flow Equation
submenus.
Press ENTER when desired fluid media is
flashing.
Press ENTER when desired flow equation is
flashing.
Press ENTER to begin setup of the Indicators
Press ENTER when Total is flashing to
configure the Totalizer Indicators
Enter the desired Total Descriptor
Enter the desired Volume Units Label for the
Totalizer.
Select the desired Total Decimal Place.
0-3 decimal places allowed.
Press ENTER when Dens is flashing to
configure the Density Indicators.
Enter the desired Density Descriptor.
Enter the desired Mass Units Label for
Density.
Select the desired Density Decimal Place.
0-6 decimal places allowed.
Enter the default density setting.
6.3.4
SETUP
INDICATORS
(Density)
SELECT FLOW EQUATION
SELECT FLUID MEDIA
Liquid Gas
SELECT FLOW EQUATION
Volume Mass Cor/Vol
Advance To
SETUP INDICATORS
(Total)
SETUP INDICATORS
SETUP INDICATORS
Tot Dns Rte Tmp Pres
TOTAL DESCRIPTOR
TOTAL
TOTAL VOLUME UNITS
gal
TOT DEC PLACES (0-3)
0
Advance To
SETUP INDICATORS
(Density)
SETUP INDICATORS
Tot
Dns Rte Tmp Pres
DENSITY DESCRIPTOR
DENS
DENSITY MASS UNITS
lbs
DENS DEC PLACES(0-6)
4
DENSITY DEFAULT
1 lbs/g
Advance To
SETUP INDICATORS
(Rate)
ENTER
ENTER
ENTER
ENTER
6.3.3
SETUP
INDICATORS
(Total)
6.3.2
SELECT
FLOW EQUATION
ENTER
ENTER
ENTER
ENTER
ENTER
