39
SP3850 Flow Computer
Sub-menus Display Notes
ADMINISTRATIVE SETUP
TAG NUMBER
FT XXXX
OPERATOR PASSWORD
****
SUPERVISOR PASSWORD
****
SOFTWARE VERSION
vxx.xx
PRODUCT ORDER CODE
SP3850xxxxxxx
UNIT SERIAL NUMBER
00000
SENSOR SERIAL NUMBER
00000
DISPLAY NEW ERR ONLY
No Yes
Advance To
SETUP NETWORK CARD
Press Enter to begin Administrative Setup.
Use the up and down arrow keys to define the
tag number.
Enter Operator Password. (Factory Set to 0)
Enter Supervisor Password, if logged in as
supervisor. (Factory Set to 2000)
This display is used to show the software
version of the installed software.
This display is used to show the product order
code (model number).
This display is used to show the unit's serial
number.
This display is used to show the sensor's
serial number.
If yes is selected, an error message will only
appear once until acknoledged by user.
Advance to Network Card only if a Network
Card is installed.
ENTER
ENTER
ENTER
6.3.23
ADMINISTRATIVE
SETUP
6.3.22
SETUP
DATALOG/PRINT
(Select_list)
ENTER
ENTER
Press enter to begin Setup Datalog/Print
routine.
Press enter when Select_list is selected to
setup print list.
Use Up and Down arrow keys to view list
status.
Press the Print or function key for the items
that you wish to add or remove from the list.
Items marked with Yes will be added to the
list,
items marked with No will be removed from
the list.
The Select Print List Information display
shows the current possible Datalog size.
SET DATALOG/PRINT
SET DATALOG/PRINT
Config
Select_list
PRINT LIST ITEMS
FLUID YES
PRINT LIST ITEMS
TIME YES
PRINT LIST ITEMS
RATE YES
PRINT LIST ITEMS
DataLog size =001489
Advance To
ADMINISTRATIVE SETUP
ENTER
ENTER
ENTER
ENTER
ENTER
STOP
START
List Items:
FLUID
TIME
RATE
TOTAL
GRAND
TEMP
DENS
PRE1
PRE2
PRESS
VISC
FREQ1
FREQ2
KA-F
KB-F
ENTER
ENTER
