Sponsler, Inc. Model T675 Flow Totalizer Technical Information Pg. 30
3.3.2.3 – Printer format 2/2
Programs which print parameters are to be outputted to the printer, their line and margin location. Typical printers
operate on a line per page and character per line basis. The first coordinate pair identifies the line location and the
second coordinate pair the position of the left hand character. Any delivery parameter not to be printed should be
assigned a 00.00 coordinate.
Note: Do not duplicate the line location coordinate pair for any parameter.
To select a parameter simply enter the corresponding number.
Example: Select Deliv UOM; <1>
******* yy.xx Printer Coordinates ******
1 – Deliv UOM
2 – Deliv info
3 – Copy#
4 – Meter#
5 – Trailer#
6 – Serial#
7 – Delivery #
8 – Title
9 – Lines/page
Enter setting (ESC to exit)?
3.3.2.3.1 – Delivery Unit of Measure
Programs whether product information is downloaded to the printer and the coordinates.
Example: Program Deliv UOM to be the 11
th
parameter outputted to the printer aligned left;
<11.01>
*************** Deliv UOM **************
Current setting = 11.01
Enter setting (ESC to exit)?
Note:
3.3.2.4 – Printer Comm
Other coordinate displays are similar to the Delivery UOM display.
Sets the printers communication parameters.
Example: Program the baud rate to communicate with the printer; <1>
************ Printer params ************
1 – Baud rate
2 – EOL character
3 – Use Bluetooth (0=NO, 1=YES)
Enter setting (ESC to exit)?
