Sponsler, Inc. Model T675 Flow Totalizer Technical Information Pg. 13
3.2.1.3 – Linearizer on/off
Activates or deactivates the linearizer function. <0> = Off, <1> = On
Example: To activate the linearizer; <1>
******* Linearizer (0=OFF, 1=ON) *******
Current setting = 1
Enter setting (ESC to exit)?
3.2.2 – Configuration
Allows setting the following parameters. Depress the corresponding category number in the left column, entry is
automatic.
**** Adjustment mode – Configuration ***
1 – Compensation (0=OFF, 1=ON)
2 – Product
3 – Units of Measure
4 – Digits right of decimal
5 – Use dual coil (0=NO, 1=YES)
6 – Printer checking (0=NO, 1=YES)
Enter setting (ESC to exit)?
3.2.2.1 – Compensation active
Activates or deactivates the temperature compensator, <0> = Off, <1>= On
Note: To operate the T675 volumetric (no temp comp) select 0.
Example: Activate temperature compensation; <1>
****** Compensation (0=OFF, 1=ON) ******
Current setting = 1
Enter setting (ESC to exit)?
3.2.2.2 – Trailer product
Selects the product to be measured. Even if compensation is not active, the proper product is required because
engineering unit of measure equivalency information is contained in the product table. Additionally, all bargraph
and alarm limits for temperature are contained in this table. Depress the corresponding product number in the left
column, entry is automatic.
Example: Select Liquid Nitrogen; <2>
**************** Product ***************
Current setting = 2
1 – LOX
2 – LIN
3 – LAR
4 – LCO2
5 – LN20
6 – CC02
7 – MAPP
8 - LPG
